More Drive Solutions For Machine Tools

Versatile Solutions For The Machine Tool Industry

As the specialist for custom gearboxes, RSGetriebe provides machine tool manufacturers with first-class drive solutions that can be customized to the machine. Energy efficiency at a high power density: the planetary, right angle planetary, control and spur gearboxes are optimally tailored to the requirements of the machine tool industry.

As one of only a few suppliers in the market, RSGetriebe offers flexibly adaptable, precision gearboxes mounted in anti-friction bearings, with powers of up to 300 kW.

Flexible and low cost – these gearboxes are characterized by standardized components, for which the machine connection dimensions are freely selectable. In conjunction with the low energy loss, the precision components from RSGetriebe set standards in the market when it comes to efficiency and economy.

Technical Data

Power

P

kW

9-300
Ratio

i



Depends on the customer’s requirements and technical feasibility
Speed

n2 max

rpm

12,500
Torque

T2 max

Nm

12,000
HousingSteel, cast iron
LubricationOil splash lubrication, oil circulation lubrication with pump or separate oil supply unit.
CoolingOil/water cooler, internal and external, oil/air cooler
